The Prisma SMART plus is an innovative and user-friendly device that offers automatic continuous pressure adjustments tailored to each patient's specific needs, ensuring highly comfortable and effective treatment. With the option to combine CPAP and APAP machine modes and featuring the softPAP pressure relief option, the Prisma SMART plus provides therapy flexibility to suit individual preferences. It also offers two different APAP dynamics, ensuring optimal therapy for every patient.
Designed with practicality in mind, the Prisma SMART plus is a versatile device that meets both patient and clinician requirements. Its intuitive interface makes it easy to use, while its reliability, cost-effectiveness, and state-of-the-art technology make it an all-round solution for sleep therapy needs.
In addition to the features of the Prisma SMART, the Prisma SMART plus includes a 15mm standard breathing tube and built-in Bluetooth capability for seamless connectivity to the Prisma APP.
Specification
| Dimensions W x H x D in cm | 17 x 13.5 x 18 |
| Weight | 1.2 kg |
| Air pressure range | 700 hPa to 1060 hPa, corresponds to an altitude of 3000 m above mean sea level; adapts automatically to altitude |
| Connection diameter of breathing tube in mm | 19.5 (fits standard tapered connector) |
| Power capacity | Max. 40 VA |
| System interface | Only connect approved accessories. |
| Materials Housing Air filter/coarse dust filter Pollen filter/fine filter Breathing tube | Flame-retardant technical thermoplastics: ASA (acrylonitrile/styrene/acrylate copolymers) with PC (polycarbonate) Polyester foam Synthetic fiber mix bonded to a PP (polypropylene) nonwoven Polyethylenes Thermoplastic elastomers No parts contain latex. |
Features
+ Two dynamic options for pressure adjustment in APAP mode
+ Deep sleep indicator prisma RECOVER for evaluation of sleep quality
+ Several convenience functions such as autoSTART, softSTART, pressure relief softPAP
+ Detection of periodic breathing, RERA, snoring, hypopnea, apnea and flow limitations
+ Intelligent networking of sleep diagnostics and sleep therapy by means of the direct connection – wireless via Bluetooth – to Lowenstein's polygraph device Samoa.
+ It‘s quiet as a whisper for the well-being and comfort of patients and partners.
Packaging & Inclusions
All dimensions are approximate, packaging includes 3 boxes & 1 piece Power Cord.
Box: 340mm x 228mm x 250mm (Prisma SMART plus APAP Therapy Set)
Box: 200mm x 170mm x 150mm (PrismaAQUA Humidifier)
Box: 320mm x 200mm x 50mm (HYBERNITE Superday Heated Breathing Tube System)
Power Cord approx. 1 metre long
Prisma SMART plus APAP Therapy Set Inclusions
Prisma SMART plus basic device
PrismaBAG basic, carrying bag
Breathing tube, 22 mm
Power supply unit
Power cord
Set of 2 air filters
SD card
Main power cable AU/NZ type I
EU type power cable
Instructions for use Prisma SMART plus/max & Prisma SOFT plus/max, EN
PrismaAQUA Humidifier inclusions
Upper part of housing
Humidifier tub
Humidifier insert
Heater rod
HYBERNITE Superday Heated Breathing Tube System inclusions
HYBERNITE Superday heated breathing tube
Power supply unit and EU type power cable
